Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft

Condition : New

Place of Origin : Zhejiang, China

Model Number : 126T2-01-silver

Dimensions : ≤126mm*137mm*210mm

Weight : ≤1.25kg

Azimuth Angle Range : 360° continuous

Pitch Angle Range : +20°~ -110° (horizontally forward is 0°)

Roll Angle Range : +30°~ -30°

Visible light television Pixels : 1920*1080

Infrared thermal imager Pixels : 640*512

Contact Now

Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Performance Overview
Dimensions
≤126mm×137mm×210mm
Weight
≤1.25kg
Azimuth Angle Range
360° continuous
Pitch Angle Range
+20°~ -110° (horizontally forward is 0°)
Roll Angle Range
+30°~ -30°
Stable Accuracy
≤0.1mrad (RMS)
Tracking Accuracy
≤0.2mrad (RMS)
Operating Temperature
-20～ +55℃
Electrical Parameters
Power Supply
12-36VDC power supply Average power consumption: ≤40W
External Interface
1 100M network digital video output (including communication)
1 RS422, 1 RS232
Video storage
microSD card
Optical parameters
Visible light television
Pixels: 1920×1080
Field of view: 2.3°×1.3°~ 63.0 °×35.4°(Focal length: 4.3mm～129mm)
Magnification: 30x optical, 60x hybrid
Distance for vehicle targets:
Detection distance: ≥6km Recognition distance: ≥4km
Infrared thermal imager
Pixels: 640×512
Field of view: 9.7°×7.8° (Focal length: 45mm)
Distance for vehicle targets:
Detection distance: ≥2.8km, Recognition distance: ≥1.4km
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
Modular Flight Storage Pod with Quick Release Mounting System and Waterproof Design for General Aviation Aircraft
1、 Are you a manufacturer or a trading company?
We have our own factory and the prices are all the lowest factory prices.Each product has been tested repeatedly by professional engineers!

2、ls it possible to get a sample?
We offer sample when you pay sample fee.

3、What about after-sale service?
12 months warranty for all kinds of products. Ourexperienced technical team is ready to respond youwithin 24 hours.

4、How to place an order?
a: Send us an inquiry.
b: Confirm your wanted product.
c: Confirm the price, freight cost and other details.
d: Complete the payment.
e: We start production and arrange the shipment.
f: Customer will receive the product.

5、 How much for the shipping cost?
According to your quantity and country. We are check the freight for you.
and choosebest shipping way.

6、How do you ensure the quality of products?
All of our products undergo strict quality control inspections during the productionprocess. Especially for exported products, a 72 hour aging test is required to ensurethat there are no issues before shipment.
